1200V 800A SiC Power Module Selection Guide for EV Traction Inverters & Energy Storage PCS
1 Introduction
Driven by the large-scale commercialization of 800V high-voltage EV platforms, energy storage PCS and high-power industrial
inverters, 1200V silicon carbide (SiC) power modules have evolved into the core hardware of high-efficiency power electronic
systems.
Against conventional silicon IGBT modules, SiC MOSFET power devices possess distinct competitive strengths:
Higher rated breakdown voltage
Significantly suppressed dynamic switching losses
Support for elevated operating switching frequencies
Improved overall system power density
Reduced volume and cost of thermal cooling systems
Global mainstream SiC module manufacturers include Infineon Technologies, ROHM Semiconductor, Wolfspeed and ON
Semiconductor.
In response to mass customer demand, Chinese semiconductor enterprise RUILIN SEMI has rolled out its proprietary 1200V
800A SiC power module dedicated to high-power inverter equipment. This article provides a full performance benchmark against
international mainstream brands.
2 Typical Application Scenarios of 1200V SiC Modules
1200V SiC power modules are widely deployed in the following power conversion equipment:
EV Traction Inverters 800V high-voltage vehicle platforms cover power grades ranging from 150 kW to 500 kW
Energy Storage PCS Standard single-unit power ratings: 250 kW, 500 kW, 1 MW
Industrial Variable Frequency Motor Drives Power coverage: 100 kW ~ 800 kW
PV & Wind Power Grid-Tied Inverters Achieve system conversion efficiency above 98%
3 Core Device Selection Evaluation Parameters
| Parameter | Evaluation Significance |
|---|---|
| Blocking Voltage | Determines system voltage safety margin |
| Continuous Rated Current | Defines maximum system output power capacity |
| On-state Resistance Rds(on) | Directly governs steady-state conduction loss |
| Switching Loss | Decides energy efficiency under high-frequency operation |
| Thermal Resistance | Critical indicator for thermal layout and heat sink design |
| Package Form Factor | Restricts mechanical integration and layout space of the whole machine |
4 Market Benchmark of Mainstream 1200V SiC Modules
| Brand | Representative Model | Voltage Rating | Rated Current | Packaging Topology | Primary Application |
|---|---|---|---|---|---|
| RUILIN SEMI | RL800N1200A | 1200V | 800A | HPD High-Current Package | New Energy Vehicles / Energy Storage |
| Infineon | FS03MR12A6MA1 | 1200V | 400–600A | Hybrid Packaging | Passenger EV Traction Inverters |
| ROHM | BSM600D12P4G | 1200V | 600A | Half-Bridge Module | Industrial Drives & Power Supplies |
| Wolfspeed | XM3 Platform Series | 1200V | 450–700A | Half-Bridge Module | New Energy Vehicles |
| ON Semi | EliteSiC Module Series | 1200V | 300–500A | Half-Bridge Module | Industrial Power Conversion Equipment |
It can be clearly seen that 800A-grade high-current SiC power modules remain a scarce product category,
targeting high-power premium system platforms.
5 Product Profile of RUILIN SEMI RL800N1200A 1200V SiC Module
RUILIN’s RL800N1200A SiC power module features the following core strengths:
Ultra-High Continuous Current Capacity 800A rated current, perfectly matching heavy-duty commercial EVs, large-capacity energy
storage PCS and high-power industrial inverters
Superior System Energy Efficiency Adopts advanced SiC MOSFET wafer technology to cut switching losses and support higher
switching frequencies, enabling overall inverter efficiency exceeding 98%
Wide High-Temperature Operating Window Maximum allowable junction temperature up to 175°C, delivering outstanding
long-term operational reliability and simplifying product cooling structural design
6 Calculated System Output Power Capacity
Under 800V DC bus voltage operating conditions, the matching inverter rated power corresponding to different module currents is as follows:
| Module Continuous Current | Matched Inverter Output Power |
|---|---|
| 400A | ~320 kW |
| 600A | ~480 kW |
| 800A | ~640 kW |
Therefore, the 800A high-current SiC module is the optimal solution for:
Heavy-duty electric trucks
Hydrogen fuel cell commercial vehicles
Large-scale grid-connected energy storage PCS equipment
7 Introduction to Module Packaging Topologies
Two mainstream packaging forms for 1200V SiC power modules:
Half-Bridge Package Advantages: Flexible inverter topology design, convenient parallel connection for power expansion
Six-Pack Integrated Module Advantages: Highly integrated, effectively reduces overall inverter equipment volume
RUILIN SEMI adopts a proprietary HPD high-current dedicated packaging structure, customized for high-power inverter
development projects.
8 Core Advantages of High-Current SiC Power Modules
High-current single-pack SiC modules bring multiple systematic optimization benefits:
Higher system power density Reduces the total quantity of power modules required for a given power grade
Lower overall BOM cost Cuts costs of supporting busbars, heat sink radiators and independent gate drive circuits
Simplified inverter mechanical design Greatly shrinks the overall outline size of power electronic assemblies
9 Conclusion
Against the backdrop of widespread penetration of 800V high-voltage EVs and large-scale energy storage systems, 1200V SiC
power modules have become mainstream core power semiconductors.
Compared with conventional 600A mid-current SiC modules, RUILIN SEMI RL800N1200A delivers larger continuous current
carrying capacity and higher single-unit inverter output power.
Target Application Fields: EV traction inverters, energy storage PCS converters, high-power industrial motor drive equipment
Complete Core Technical Specifications
| Parameter | Spec Value |
|---|---|
| Model Number | RL800N1200A |
| Rated Blocking Voltage Vds | 1200 V |
| Continuous Drain Current Id | 800 A |
| On-state Resistance Rds(on) | Ultra-low |
| Switching Energy Eon/Eoff | Extremely low (native SiC material advantage) |
| Maximum Junction Temperature Tj,max | 175°C |
| Package Form | HPD high-current dedicated package |
| Internal Topology | Half-bridge, customizable layout |
| Target Applications | EV traction inverters, energy storage PCS, industrial high-power drives |
| Matching System Power (800V DC Bus) | ~640 kW |
Core Product Advantages
Higher power density, reduced total system cost, simplified mechanical and thermal design
High-current SiC power modules will serve as a critical hardware solution for next-generation high-power power electronic systems.
